Features :
• Precise design terminal type adequate for DIP IC pitch size (multiple of 2.54mm).
• Epoxy sealing treatment, free of flux entry.
• Several LED colors options.
• Several cap legends options.
• Customized cap and legend are available.
Applications :
Operating switches in all types of electronic equipment such as audio apparatus, office equipment, communications apparatus, TV ets, VCRs, etc.
| Rating | 0.1A 30VDC |
|---|---|
| Insulation Resistance | 100MΩ Min (at 500 VDC) |
| Dielectric Strength | AC 500V (50/60 Hz for 1 minute) |
| Contact Resistance | 50mΩ Max. (Initial) |
| Electrically Life | 10,000 Cycles Min |
| Ambient Temperature | -10°C~ +80°C |
| Operating Force | 150 ± 100gf (Momentary) |
| 250 ± 100gf (Alternate) | |
| 200 ± 100gf (Momentary With Click) |
| Color | VR | IF | Recommended Operating Current |
VF | |
|---|---|---|---|---|---|
| Nor | Max | ||||
| Red | DC 5V | 20mA | 20mA | 1.7V | 2.4V |
| Green | DC 5V | 20mA | 20mA | 1.9V | 2.4V |
| Yellow | DC 5V | 20mA | 20mA | 1.9V | 2.4V |
| Blue | DC 5V | 20mA | 20mA | 3.0V | 3.6V |
| White | DC 5V | 20mA | 20mA | 3.0V | 3.6V |
For the specification about the other LEDs, please contact with sales department
