Features :
• DPDT.SPST Tactile feeing. Illuminated 12X17 &12x12mm.
• Several LED colors options.
Applications :
• Operating switches in all types of electronic equipment such as audio apparatus, office equipment, communications apparatus, TV sets, VCRs, etc.
| Rating | 5A 125 / 250VAC or 5A 30VDC |
|---|---|
| Insulation Resistance | 200MΩ Min (at 500 VDC) |
| Dielectric Strength | AC 500V (50/60 Hz for 1 minute) |
| Contact Resistance | 50mΩ Max. (Initial) |
| Electrically Life | 10,000 Cycles Min |
| Ambient Temperature | -25°C~ 50°C |
| Operating Force | 190 ± 50gf single pole |
| 250 ± 50gf Double pole |
| Color | VR | IF | Recommended Operating Current |
VF | |
|---|---|---|---|---|---|
| Nor | Max | ||||
| Red | DC 5V | 20mA | 20mA | 1.5V | 2.6V |
| Green | DC 5V | 20mA | 20mA | 1.9V | 2.6V |
| Yellow | DC 5V | 20mA | 20mA | 1.9V | 2.6V |
| Blue | DC 5V | 20mA | 20mA | 3.5V | 4.0V |
| White | DC 5V | 20mA | 20mA | 3.5V | 4.0V |
For the specification about the other LEDs, please contact with sales department
