Features :
• SPST, Tactile feeling, illuminated 18X20 mm push switch LED RGB.
• Dimension 14mm*23mm*26mm.
Applications :
• Operating switches in all types of electronic equipment such as audio apparatus, office equipment, communications apparatus, TV sets, VCRs, etc.
| Rating | 50mA 12VDC |
|---|---|
| Insulation Resistance | 100MΩ Min (at 100 VDC) |
| Dielectric Strength | AC 250V (50/60 Hz for 1 minute) |
| Contact Resistance | 200mΩ Max. (Initial) |
| Electrically Life | 300,000 Cycles Min |
| Ambient Temperature | -10°C~ +60°C |
| Operating Force | 200 ± 100gf |
| Color | VR | IF | Recommended Operating Current |
VF | |
|---|---|---|---|---|---|
| Nor | Max | ||||
| Red | DC 5V | 30mA | 20mA | 1.9V | 2.5V |
| Green | DC 5V | 30mA | 20mA | 3.3V | 4.1V |
| Yellow | DC 5V | 30mA | 20mA | 3.3V | 4.0V |
For the specification about the other LEDs, please contact with sales department
